Debug and view Windows .dmp files.

Quick and short post.

Nowadays if a BSOD happens in Windows, the OS automatically restarts the system. The users in an enterprise never notice that an BSOD just occured, but will find their computer automatically rebooting and as a result hereof, the users calls the helpdesk.

If a BSOD just happened, windows will log the errors in .dmp files. Typical location is %SystemRoot%\MEMORY.DMP

To view the .dmp files, you will need  the Windows Software Development Kit (SDK). This one is for Windows 8.1:

Following the SDK, comes windbg.exe. This is the tool that allows you to view the content of the .dmp files.

Before opening any .dmp files, you will need to specify a symbol search path. You do so by launching WinDbg and click File -> Symbol File Path.

Insert following path: SRV*C:\Symbols*

(Replace the text in bold with your preffered location for the symbols)

More on the symbols:


Software Updates and KB3000850 (failed installing updates with error 0x8024000b)

Microsoft just released a major update for Windows 8.1 and Server 2012 R2. A so called Update Rollup for November 2014:

KB3000850 is treated as any other updates, and is being downloaded and deployed with my Configuration Manager 2012 environment.

Doing so out of the box was however not without obstacles. The updates is classified as a regular update, and therefore has a max. runtime set to 10 minutes.

Deploying the update as it is, was resulting in a failed status, and this in the WindowsUpdate.log:

WARNING: WU client failed installing updates with error 0x8024000b

This translates into maximum runtime exceeded, so you will have to go ahead and change that.


The update has a size of a service pack, so I allowed 60 minutes just be sure.


Troubleshooting boundaries and content download

I’m currently investigating some potential boundary issues related to the use of AD sites. Therefore I was looking for some more details on how content download is behaving considering slow and fast links in the environment.

This is some of the tests I did and the results thereof:

Action: Deploying software-package as available to a client which is within a slow boundary.

Result: Policy is received and entry in Software Center visible. Launching the installation gives following entry in the execmgr.log:

Action: Change the deployment options to Download content from distribution point and run locally when the client is within a slow or unreliable boundary. Refresh machine policy, and run the installation from Software Center again.

Result: This time execmgr.log immediately respondend with a successful content request.


And while digging further into LocationServices.log, do notice following entries:

Distribution Point=’http://DP1.MYDOMAIN.COM/SMS_DP_SMSPKG$/KR1002C4′, Locality=’REMOTE’, DPType=’SERVER’, Version=’7958′, Capabilities='<Capabilities SchemaVersion=”1.0″><Property Name=”SSLState” Value=”0″/></Capabilities>’, Signature=’http://DP1.MYDOMAIN.COM/SMS_DP_SMSSIG$/KR1002C4′, ForestTrust=’TRUE’,
Distribution Point=’http://DP2.MYDOMAIN.COM/SMS_DP_SMSPKG$/KR1002C4′, Locality=’REMOTE’, DPType=’SERVER’, Version=’7958′, Capabilities='<Capabilities SchemaVersion=”1.0″><Property Name=”SSLState” Value=”0″/></Capabilities>’, Signature=’http://DP2.MYDOMAIN.COM/SMS_DP_SMSSIG$/KR1002C4′, ForestTrust=’TRUE’,

Locality=’REMOTE’, which identifies the client as being in a slow and unreliable boundary, which in this case is very true, but the software deployment is still running because of the change of options on the deployment.

When a client is within a fast and reliable boundary of the site, the entry would look like this, as in the locality of the client is local.

Distribution Point=’http://DP1.MYDOMAIN.COM/SMS_DP_SMSPKG$/KR1002C4′, Locality=’LOCAL’, DPType=’SERVER’, Version=’7958′, Capabilities='<Capabilities SchemaVersion=”1.0″><Property Name=”SSLState” Value=”0″/></Capabilities>’, Signature=’http://DP1.MYDOMAIN.COM/SMS_DP_SMSSIG$/KR1002C4′, ForestTrust=’TRUE’,

Client logs to consider when troubleshooting boundaries and content download:


Default Search Provider – Internet Explorer

Making Google the default search provider in Internet Explorer during OSD, is no trivial task. For many years, I have done so using an answer file to the Apply Operating System step in the task sequences.

And so, it was no different when I recently rebuilt our Windows 8.1 image:


Above config of the answer file would previously remove the bing search engine, and replace it with google. Notice the ScopeDefault being set to true.

Something has changed though, and Bing now remains as default in Internet Explorer, but Google is however added. Strange.

I’m currently still looking into why the behaviour has changed, but until then I decided to go with a workaround. Forcing the search provider to be set to Google using a custom group policy.

Configure following GPO: User Configuration -> Administrative Templates -> Windows Components -> Internet Explorer : Restrict search providers to a specific list.

With this in place, the only search providers available to Internet Explorer, will be those which is found in HKCU\Software\policies\Microsoft\Internet Explorer\SearchScope. However, you’re not allowed to edit the content of this part of the registry manually (or with commands). You will need a custom made group policy, and luckily you can find one here: download (I found this somewhere else, and edited if for my use. It had other search engines, as well as an outdated string for google)

Import it as always, and the result will be this:


As the help text suggests, this will put the required registry entries in place, and with only Google selected, Google will be the only and therefore default. (As 99.9% of users would prefer. Except Microsoft employees)

Restore Windows 8 built-in Apps

I just ran into an issue, where none of the built-in apps in Windows 8 was able to run. That including “Change PC Settings” accessed from the Charms Bar.

The event logs was showing following entry:

Event 5973, Apps

Activation of! failed with an error: This app failedto launch because of an issue with it’s license. Please try again in a moment. See the Microsoft-Windows-TWinUI/Operation log for additional information.

All the apps are stored in the profile, and something eventually broke them: %userprofile%\AppData\Local\Packages.

To fix them again following powershell commands can be run. (a lot of post on the internet says, that the commands has to be run from an elevated prompt. I guess that only goes, if the user already is a local admin. All apps are user-based, and doesn’t require admin privileges)

So initiate a cmd.exe as the user who’s logged on, and run these:

powershell -ExecutionPolicy Unrestricted Add-AppxPackage -DisableDevelopmentMode -Register $Env:SystemRoot\WinStore\AppxManifest.xml
powershell -ExecutionPolicy Unrestricted Add-AppxPackage -DisableDevelopmentMode -Register $Env:SystemRoot\ImmersiveControlPanel\AppxManifest.xml
powershell -ExecutionPolicy Unrestricted Add-AppxPackage -DisableDevelopmentMode -Register $Env:SystemRoot\FileManager\AppxManifest.xml
powershell -ExecutionPolicy Unrestricted Add-AppxPackage -DisableDevelopmentMode -Register $Env:SystemRoot\Camera\AppxManifest.xml


Unlocking ConfigMgr 2012 objects

Hurray for powershell!

The ConfigMgr console crashes, and the objects you were working on are locked. For the next 30 minutes.

Since ConfigMgr 2012 SP1 we have following cmdlet to our rescue:

Unlock-CMObject -InputObject $(Get-CMTaskSequence -Name “Install Application – DocsCorp Apps”)

In this scenario I was working on a task sequence called Install Application – DocsCorp Apps, when my console crashed.

Connect to Windows Powershell through the ConfigMgr console to load the proper module, and use the above cmd to unlock the object.

Following cmds are available:


Removing Office Updates (KB2863908) with msiexec.exe

Ouch, ever been in need of removing an Windows update? Usually this is often done when a particular update is interfering with an internal application, and normally this can be achieved with the wusa.exe tool:

WUSA.exe /uninstall /kb:2863908

But this has proven only to be working if the KB is related to Windows, else you will be getting this error: The update is not installed on this computer.


The correct answer to get rid of the update (besides uninstalling it manually) lies within the registry. Searching for the KB in question will give you a key named UninstallString with a value equal to this:

“C:\Program Files (x86)\Common Files\Microsoft Shared\OFFICE15\Oarpmany.exe” /removereleaseinpatch “{90150000-0011-0000-0000-0000000FF1CE}” “{6764E50D-D076-41BC-B069-08DD488AE88B}” “1033” “0”

Running this command directly will also remove the mentioned update, but will require manual intervention (we don’t like to do stuff manually)

However, you can use these values with the Windows Installer: msiexec.exe:

msiexec.exe /package {90150000-012B-0409-0000-0000000FF1CE} MSIPATCHREMOVE={6764E50D-D076-41BC-B069-08DD488AE88B}

Enjoy 🙂

Managing workgroup/DMZ clients with ConfigMgr

For security reasons, we have decided to join specific computers, serving a specific role to a workgroup instead of our domain. While being in a workgroup in the DMZ, we still had the need to manage them using ConfigMgr.

I had no previous experience in managing DMZ workgroup computers, so I had to gather the required know-how.

This is what I did:

  • Listed the limitations regarding workgroup clients. (No Active Directory)
  • Created the proper boundaries for the workgroups clients. (If no boundaries are created, all clients will be considered as a slow client)
  • Made sure that port 80 (CM) and port 8530 (WSUS) are forwarded to through the firewalls to the new network.

As the workgroup clients are on their own network, and without DNS to give them information about which and where to locate a Management Point, we had to make following changes to the host files (C:\Windows\System32\drivers\etc) on the clients:



With these changes in place, you can install the CM client with following commandline: “ccmsetup.exe” SMSSITECODE=SITECODE

If installing the client from an OSD task sequence, you cannot use the SMSSITECODE property (We have a seperate OSD TS for these clients joining a workgroup).

When the client is installed successfully, you will be able to see the client in the SCCM console. Note that the client is not automatically approved (This can be changed to automatically auto approve all sorts of clients, but is not recommended)


After manually approving the client in the console, the client will start to download policies from the Management Point. (To speed up this process, you can restart the ccmexec service)

In the initial phase of getting this to work, it’s a really good idea to watch the proper log files, to see what actually happens, and in case of any errors, take the required actions.

These are some of the important client logs to consider:


Enjoy… 🙂

Tattoo and inventory the registry

OBS: This post is primary about how to tattoo the registry with any given information, and then inventory it with SCCM2012.

In need of knowing when a client got it’s OS intalled/reinstalled? Read further. There is no built-in feature in ConfigMgr, that quickly enables you to find that piece information, which basically means we have to make our own.

In following post I will explain what I do, using hardware inventory in ConfigMgr 2012.

First off, we have to make sure that the information we need, in this instance, the date of OS deployment is created during the actual installation. This can be achieved in various ways. I choose to add an entry to the registry.

Running following commandline from within your OS task sequence does just that:

reg add “HKLM\Software\COMPANYNAME” /v InstallDate /t REG_SZ /d “%date%”


With this in place, we have what we need on the clientside. The command will leave a trace of the actual date of when the computer got installed.

Now we need to tell ConfigMgr how to use this, and for this I use hardware inventory.

Hardware inventory means changes to the configuration.mof. Download and use RegKeyToMof will make your life easier on this one: Download here

What you basically need to do, is to browse your way to the registrykey you wish to inventory. In this case HKLM\Software\COMPANYNAME\ and check off InstallDate. RegKeyToMof will automatically generate the necessary snippet of code to be inserted into the configuration.mof file and for your Client Settings in the ConfigMgr console.



Client Settings:


Now update the client’s policy, run a new hardware inventory cycle and monitor the log files. InventoryAgent.log on the client, and dataldr.log on the server are relevant in this case. Datalgr.log vil start updating once the changes to configuration.mof has been done.

If everything goes as expected, you will be able to run a resource explorer on the client from the ConfigMgr console, and see something similar to this:


And finally from here, you will be able to use this information in queries or even build a report, and this way locate clients which haven’t been reinstalled for a long period of time.


Edit default user registry hive

You can apply registry settings in various ways, but sometimes you might consider making a setting default, not only for the current users of a computer, but also for every new user. This is already achieveable through Group Policies you might think, and that is true. What I prefer to do however, is to make changes to the default user. You can do that during deployment of the OS, and therefore limit the changes coming from your group policies. (Awesome!)

Consider this: You have decided to show the icon for This PC on the desktop on Windows 8, and would like that for every future users of your computers in the environment.

This is what I do:

Create a simpe batch script containing following:


This will make changes to the default user, and all future userprofiles created on the computer, will have this change.
