ConfigMgr 1511 – Notes from the field

I just updated my ConfigMgr environment to 1511 (CurrentBranch) and while the installation itself went safe and sound, following is to be noted:

  • The new Software Center never got installed properly with a shortcut in the start menu (%ProgramData%\Microsoft\Windows\Start Menu\Programs\Microsoft System Center\Configuration Manager)
    I had to re-enable the setting in my Client Settings (Disable the feature, OK, Enable the feature, OK and do another policy refresh)

ClientSettings

  • None of the new Windows 10 1511 software updates was synced into SCCM. I checked WSUS manually, and the classification Upgrades was not selected regardless of the Upgrades being indeed selected in SCCM. To solve this, I had to de-select all classifications in SCCM and select them again on the Software Update point. When I checked the chosen classifications in WSUS again, the proper selections was inherited from SCCM as expected and the next sync downloaded the Windows 10 Upgrades.

Classifications

Activate Windows 10 clients with KMS

Looking to activate your shiny new Windows 10 clients with your KMS? This is what you need to do.

1) Install following update on your KMS host: https://support.microsoft.com/en-us/kb/3058168 (Select the OS of your KMS. Reboot is required.)

2) While we are waiting for  Windows Server 2016, MS has created an unique KMS key for the use of activating Windows 10 clients with a Server 2012 R2 key. Browsing your licensing site, you will find a key named like this: Windows Srv 2012R2 DataCtr/Std KMS for Windows 10

3) Install the new key with the usual command: slmgr.vbs /ipk NEWKEYGOESHERE

4) Activate the key using: slmgr.vbs /ato

5) Lean back and watch your W10 clients being activated by your KMS.



New PXE deployments: “Skipping Task Sequence because it is not active yet”

I just updated to Windows 10 ADK and was eager to start building my new Windows 10 image.

So I created brand new WinPE10 boot images (x64/x86), deployed them to my DP’s and PXE points. Imported the new OS into SCCM and created my build and capture TS and deployed it to my BuildCapture collection. I booted my VM and noticed my new task sequence wasn’t on the list. I did another reboot just to make sure the new policy was downloaded, but no. Still no W10 build and capture task sequence.

Having a look at the SMSTS.log revealed following: “Skipping Task Sequence because it is not active yet”

Seems like the time is a bit off when deploying with a default available schedule of now. I had to edit the deployment and set the date/time a few days back for the TS to show up. (This is CM 2012 R2 SP1)



Debug and view Windows .dmp files.

Quick and short post.

Nowadays if a BSOD happens in Windows, the OS automatically restarts the system. The users in an enterprise never notice that an BSOD just occured, but will find their computer automatically rebooting and as a result hereof, the users calls the helpdesk.

If a BSOD just happened, windows will log the errors in .dmp files. Typical location is %SystemRoot%\MEMORY.DMP

To view the .dmp files, you will need  the Windows Software Development Kit (SDK). This one is for Windows 8.1: https://msdn.microsoft.com/da-DK/windows/desktop/bg162891

Following the SDK, comes windbg.exe. This is the tool that allows you to view the content of the .dmp files.

Before opening any .dmp files, you will need to specify a symbol search path. You do so by launching WinDbg and click File -> Symbol File Path.

Insert following path: SRV*C:\Symbols*http://msdl.microsoft.com/download/symbols

(Replace the text in bold with your preffered location for the symbols)

More on the symbols: http://support2.microsoft.com/kb/311503
